Container Network Interface (CNI)

License: Apache-2.0

Container Network Interface (CNI) Logo

Field Guide

Complete Guide

The Container Network Interface (CNI) is a specification and set of libraries for configuring network interfaces in Linux containers. Originally built by CoreOS for rkt, it is now the networking plugin API used by Kubernetes, OpenShift, Cloud Foundry, Mesos, containerd, CRI-O, Podman, and Kata Containers.

The contract is deliberately tiny. A runtime calls a CNI plugin binary with a JSON config on stdin and a command (ADD, DEL, CHECK, GC) plus environment variables identifying the container’s network namespace. The plugin sets up (or tears down) the interface — creating veth pairs, bridges, routes, IPAM allocations — and returns a JSON result describing IPs and DNS. Plugins can be chained: a typical Kubernetes node runs an IPAM plugin (host-local) followed by a main plugin (bridge, ptp) and a portmap or bandwidth plugin.

The containernetworking/cni repo ships the spec and libcni; containernetworking/plugins ships the reference plugins (bridge, macvlan, ipvlan, host-local, loopback, portmap, bandwidth, firewall). In production, most Kubernetes clusters run a higher-level CNI implementation instead: Cilium, Calico, Flannel, Weave, or the AWS/Azure/GCP cloud-provider plugins. CNI itself is the thin interface that lets all of them plug into the same runtime.

CNCF Project

Cloud Native Computing Foundation

Accepted: 2017-05-23
Incubating: 2017-05-23
